Refrigerator sheet metal melt pump

Introduction to Refrigerator Sheet Melt Pump

The sheet metal melt pump can be used to produce insulation skins for pipes, sheets, films, substrates, and cables. Polymers are transported, pressurized, and metered.

Structure of sheet extrusion melt pump

The melt pump of the plate extruder mainly consists of a pump casing, driving gear, driven gear, sliding bearings, front and rear end plates, and packing seals.

Advantages of Plate Melt Pump

1. Optimized tooth shape design ensures more stable transportation with minimal fluctuations.

2. The flow channel design without dead corners, without material residue.

3. A simpler sealing method.

4. Optional wear-resistant configuration, suitable for high filling conditions.

Sheet melt pump parameters

Transmission medium viscosity: 1-40000Pas

Suction pressure: 0-30MPa

Output pressure: 0-40MPa

Allowable pressure difference: 25MPa

Operating temperature: ≤ 350 ℃
